D-Link DAP-1330 Quick Installation Guide

DAP-1330
3
ENGLISH
PRODUCT SETUP
SETUP
SET UP DAP-1330 WITH QRS MOBILE APP
The DAP-1330 can be configured using your smartphone. Search for "D-Link QRS
Mobile" on the Apple App Store or Google Play, and download the app. Next, connect
your smartphone to the DAP-1330 using the SSID and Password information provided on
the Wi-Fi Conguration Card and follow the helpful in-app prompts, or refer to the product
manual for more information.
SET UP DAP-1330 WITH A WEB BROWSER
The DAP-1330 can also be configured using a web browser. Once you have
plugged the DAP-1330 into a wall outlet within wireless range of your router
or connected to your existing wired network, open the wireless utility on
your computer, select the name (SSID) of the DAP-1330 network, and enter
the password (both of these are found on your Wi-Fi Configuration Card).
Next, open a web browser (e.g. Internet Explorer, Firefox, Safari, or Chrome) and enter
http://dlinkap.local./ By default, the username is Admin, and the password eld should
be left blank. Please refer to the product manual for further information on conguring the
DAP-1330 using a web browser.
TROUBLESHOOTING
SETUP AND CONFIGURATION PROBLEMS
1. HOW DO I RESET MY DAP-1330 N300 WI-FI RANGE EXTENDER TO FACTORY DEFAULT
SETTINGS?
- Ensure the product is powered on.
- Using a paperclip, press and hold the reset button on the bottom of the device for 5
seconds.
Note: Resetting the product to the factory default will erase the current conguration
settings. The default Wi-Fi network name (SSID) and password are printed on
the DAP-1330's Wi-Fi Conguration Card.
2. HOW DO I CONNECT A PC OR OTHER DEVICE TO THE DAP-1330 IF I HAVE FORGOTTEN
MY WI-FI NETWORK NAME (SSID) OR WI-FI PASSWORD?
- If you haven't changed the extended Wi-Fi network's settings, you can use the
network name (SSID) and Wi-Fi password on the Wi-Fi Conguration Card.
- If you did change the network name (SSID) or Wi-Fi password and you did not record
this information on the Wi-Fi Conguration Card or somewhere else, you must reset
the device as described in Question 1 above.
- It is recommended that you make a record of this information so that you can easily
connect additional wireless devices in the future. You can use the included Wi-Fi
Conguration Card to record this important information for future use.

D-Link DAP-1330 Specifications

General

Product color	White
LED indicators	Yes
Maximum data transfer rate	100 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u
Interface	Wi-Fi/Ethernet
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA, WPA2, WPS
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Operating altitude	5 - 95 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, IC, CE, C-Tick, CB, UL

Weight and Dimensions

Weight	86.9 g
Dimensions (WxDxH)	77 x 55.5 x 34 mm
