D-Link DAP-1360 Quick Installation Guide

DAP-1360 Quick Installation Guide
4. Select the Use the following IP address radio button and enter the
value 198.168.0.51 in the IP address field. The Subnet mask
field will be filled in automatically. Click the OK button.
5. Click the ОК button in the connection properties window.
Now you can connect to the web-based interface of DAP-1360 for configuring
all needed parameters. To gain access to an external network (to the Internet),
you also need to specify the default gateway and the addresses of DNS servers.
5

D-Link DAP-1360 Specifications

Power

power input	5V DC/1.2 A
power adapter socket	external power adapter

Operating Environment

operating temperature	0 ˚C to 55 ˚C
storage temperature	10 ˚C to 70 ˚C
operating humidity	10% to 90% non-condensing

Weight and Dimensions

weight	215 grams
dimensions	147.5 x 113 x 31.5 mm
