D-Link DAP-1360 Quick Installation Guide

DAP-1360 Quick Installation Guide
Selecting Operation Mode
By default, the access point mode is specified for the device. If you need to use
the device as a router, on the advanced settings page, select the Router
position ( ) of the Switch device mode switch. In the
opened dialog box, click the OK button to save new settings and immediately
reboot the access point.
Also you can change the operating mode of the device on the System /
Device mode page. To do this, on the page, select the Router value from the
Work mode list, and click the Change button. In the opened dialog box,
click the OK button and wait until the device is rebooted.
18

D-Link DAP-1360 Specifications

Power

power input	5V DC/1.2 A
power adapter socket	external power adapter

Operating Environment

operating temperature	0 ˚C to 55 ˚C
storage temperature	10 ˚C to 70 ˚C
operating humidity	10% to 90% non-condensing

Weight and Dimensions

weight	215 grams
dimensions	147.5 x 113 x 31.5 mm
