D-Link DAP-1360 Quick Installation Guide

DAP-1360 Quick Installation Guide
Configuring Wi-Fi Adapter in OS Windows XP
1. Click the Start button and proceed to the Control Panel > Network
and Internet Connections > Network Connections window.
2. In the Network Connections window, right-click the relevant
Wireless Network Connection icon. Make sure that your Wi-Fi
adapter is on, then select the Properties line in the menu displayed.
3. In the Wireless Network Connection Properties window, on the
General tab, select the Internet Protocol (TCP/IP) line. Click the
Properties button.
4. Select the Use the following IP address radio button and enter the
value 198.168.0.51 in the IP address field. The Subnet mask
field will be filled in automatically. Click the OK button.
5. Click the ОК button in the connection properties window.
9

D-Link DAP-1360 Specifications

Power

power input	5V DC/1.2 A
power adapter socket	external power adapter

Operating Environment

operating temperature	0 ˚C to 55 ˚C
storage temperature	10 ˚C to 70 ˚C
operating humidity	10% to 90% non-condensing

Weight and Dimensions

weight	215 grams
dimensions	147.5 x 113 x 31.5 mm
