D-Link DAP-2360 Command Line Interface Reference Manual

AirPremier N Dual Band PoE Access Point Command Line Interface Manual
16
3
LAN COMMANDS
LAN Commands Description
set arpspoofing Set ARP Spoofing
get arpspoofing Display ARP Spoofing
get ethernetcount Display Ethernet count
get gateway Display gateway IP address
get ipaddr Display IP address
get ipmask Display IP subnet mask
get ipmode Display IP mode
set gateway Set gateway IP address
set ipaddr Set IP address
set ipmask Set IP subnet mask
set ipmode static Static mode
set ipmode dynamic DHCP mode

D-Link DAP-2360 Specifications

General

Frequency band	2.4 - 2.4835 GHz
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	150 Mbit/s
Quality of Service (QoS) support	Yes
Networking features	Fast Ethernet
Wireless technology	802.11b/g/n
Compliance industry standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Antenna gain level (max)	5 dBi
Internal	No
Certification	FCC, UL 2043
Interface	Ethernet
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, SSH, SSID, WPA, WPA2
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Power supply type	AC/DC
Power consumption (typical)	9 W
Package depth	272 mm
Package width	204 mm
Package height	114 mm
Package weight	1306 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1843 mm
Pallet gross weight (air)	323840 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	294 mm
Shipping (inner) case height	244 mm
Shipping (inner) case length	600 mm
Shipping (inner) case weight	7270 g
Shipping (inner) case net weight	4500 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	166 mm
Width	188 mm
Height	36 mm
Weight	689 g
Dimensions (WxDxH)	166 x 37 x 188 mm
