D-Link DAP-2695

D-Link DAP-2695 Quick Install Guide
6
ENGLISH
Method 2
1. Connect one end of an Ethernet cable into the Data In port on
the PoE base unit and the other end into one port on your switch,
router, or computer.
2. Connect one end of an Ethernet cable into the P+Data Out port on
the PoE base unit and the other end into the LAN1 (PoE) port on
the DAP-2695 access point.
3. Use the supplied power adapter. Connect the power adapter to the
Power In receptor on the PoE adapter.
4. Connect the other end of power adapter into a power outlet.
