D-Link DAP-2695 Quick Installation Guide

D-Link DAP-2695 Quick Install Guide
7
ENGLISH
Method 3
1. Connect one end of your Ethernet cable into the LAN1 (PoE) or
LAN2 port on the DAP-2695 and then connect the other end to a
switch, router, or computer.
2. Use the supplied power adapter. Connect the power adapter to the
Power receptor on the DAP-2695 access point.
3. Connect the other end of power adapter into a power outlet.

D-Link DAP-2695 Specifications

Operating Environment

operating temperature	0˚C to 40˚C
storage temperature	-20˚C to 65˚C
operating humidity	10%~90% (non-condensing)
storage humidity	5%~95% (non-condensing)

Power

operating voltage	48V DC +/- 10% for PoE
voltage and current for PoE	48V/0.5A

Wireless Specifications

wireless frequency range	2.4 to 2.4835 GHz and 5.15 to 5.85 GHz
antenna type at 2.4GHz	3x Detachable 4 dBi Omni antennas
antenna type at 5GHz	3x Detachable 6 dBi Omni antennas

Weight and Dimensions

length	198.8 mm
width	190 mm
height	36.5 mm
