DAP-400P Quick Installation Guide
Wireless Module Parameters
HT80
-76dBm at MCS0
-73dBm at MCS1
-71dBm at MCS2
-68dBm at MCS3
-64dBm at MCS4
-60dBm at MCS5
-59dBm at MCS6
-58dBm at MCS7
-53dBm at MCS8
-51dBm at MCS9
Modulation schemes · 802.11a: BPSK, QPSK, 16QAM, 64QAM with OFDM
· 802.11b: DQPSK, DBPSK, DSSS, CCK
· 802.11g: BPSK, QPSK, 16QAM, 64QAM with OFDM
· 802.11n: BPSK, QPSK, 16QAM, 64QAM, 256QAM with
OFDM
· 802.11ac: BPSK, QPSK, 16QAM, 64QAM, up to
256QAM with OFDM
Physical Parameters
Dimensions (L x W x H)
· 213 x 213 x 38 mm (8 x 8 x 1.5 in)
Operating Environment
Power
· 48V, 0.5A or 802.3at PoE
· External DC power adapter 12V/1A (not included in the
delivery package)
Temperature
· Operating: from 0 to 40 °C
· Storage: from -20 to 65 °C
Humidity
· Operating: from 10% to 90% (non-condensing)
· Storage: from 5% to 95% (non-condensing)
44
