D-Link DCS-5220 Quick Install Guide

19 D-Link DCS-5220 Quick Install Guide
Add a Camera
To start IP surveillance, click on Windows
®
Start > Programs >
D-Link > IP surveillance > Monitor.
Once the Authentication screen
appears, enter “admin” as your
Username and the Password
that was entered during the
installation of IP surveillance.
Add a Camera
The IP surveillance Monitor screen will appear as shown below.
On the menu to the left, click the Conguration button and select
Camera Conguration.

D-Link DCS-5220 Specifications

Operating Environment

operating temperature	0˚ to 40˚C (32˚- 104˚F)
storage temperature	-40˚ to 70˚C (-14˚ - 158˚F)
humidity	Max. 95% RH

Power

external power supply	12V DC 1.5A
power consumption	4.8 Watts

Camera Specifications

cmos sensor	1/4”
minimum illumination	0.5 Lux @ F2.0
viewing angle horizontal	270º
viewing angle vertical	90º

Video and Audio

video resolution at 160x120	Up to 30fps
video resolution at 176x144	Up to 30fps
video resolution at 320x240	Up to 30fps
video resolution at 640x480	Up to 30fps
audio bitrate AAC	16kbps~128kbps
audio bitrate GSM-AMR	4.75kbps~12.2kbps

Weight and Dimensions

width	4.1”
height	4.4”
depth	4.3”
item weight	0.7 lbs
packaging weight	2.9 lbs
