D-Link DCS-5220 Quick Install Guide

6D-Link DCS-5220 Quick Install Guide
Software Installation
Turn on the computer and Insert the D-Link DCS-5220 CD into
the CD-ROM drive. The following step-by-step instructions shown
here are demonstrations in Windows
®
XP, and are similar to other
Windows
®
operating systems.
If the CD Autorun function does not automatically start on your
computer, click Windows
®
Start > Run. In the Run command box
type “D:\DCS5220.exe”, where D: represents the drive letter of your
CD-ROM. If it does start, proceed to the next screen.
The InstallShield Wizard window
will appear.
Software Installation
Click Installation Wizard
Click Next

D-Link DCS-5220 Specifications

Operating Environment

operating temperature	0˚ to 40˚C (32˚- 104˚F)
storage temperature	-40˚ to 70˚C (-14˚ - 158˚F)
humidity	Max. 95% RH

Power

external power supply	12V DC 1.5A
power consumption	4.8 Watts

Camera Specifications

cmos sensor	1/4”
minimum illumination	0.5 Lux @ F2.0
viewing angle horizontal	270º
viewing angle vertical	90º

Video and Audio

video resolution at 160x120	Up to 30fps
video resolution at 176x144	Up to 30fps
video resolution at 320x240	Up to 30fps
video resolution at 640x480	Up to 30fps
audio bitrate AAC	16kbps~128kbps
audio bitrate GSM-AMR	4.75kbps~12.2kbps

Weight and Dimensions

width	4.1”
height	4.4”
depth	4.3”
item weight	0.7 lbs
packaging weight	2.9 lbs
