D-Link DCS-8325LH

DCS-8325LH
9
ENGLISH
Mounting
4/
Twist the screws into the
anchors, leaving the tops
of the screws exposed
from the surface. Do not
over tighten the screws.
5/
Align the mounting holes
on the bottom of the
camera with the screws.
Slide the camera down to
lock it into place.
6/
Twist the camera to your
desired position. Go to the
settings in the app and
enable Invert Image if the
image is upside down.
2.6 ~ 3.0 mm
2.6~3.0mm
2.6~3.0mm
