13D-Link DCS-8620LH User Manual
Section 2 - Installation
Twist the camera clockwise onto the mounting bracket until it securely
locks into place.
4/
5/
Align the mounting bracket’s holes over the plastic anchors. Drive the screws
into the anchors to secure the mounting bracket.
For outdoor installations: This device is designed to be installed under eaves or similarly covered locations, and does not support inverted
installation. Please ensure that the device is installed with the rubber plug pointed downwards towards the ground, and that it is not installed in
an area where it will experience continuous water exposure.
