12D-Link DCS-8620LH User Manual
Section 2 - Installation
Place the mounting bracket against the wall where you want the device
to be positioned. Use a pencil to make two marks where the holes are
located.
Note: The mounting bracket is attached to the bottom of the device.
Turn the mounting bracket counterclockwise to detach it.
Use a 6 mm drill bit to drill two 26 mm deep holes over the pencil marks.
1/
2/
3/
Wall/ Ceiling Mount
The device can be mounted on a wall or on the ceiling.
Hammer in the plastic wall anchors to support the screws.
