D-Link DCS-960L User Manual

52D-Link DCS-960L User Manual
Section 4 - Security
1. Find Your Camera’s Local IP Address
Use the mydlink Home app to set up your DCS-960L. Use a web browser on your PC to go to the www.mydlink.com website and log in to your
account. Select your camera, click on the Settings tab, then click on the Advanced Settings button. Use the User name admin and the password
you created while setting up the camera. If you did not create a password, the default password is blank. After entering your password, click OK.
After logging into the conguration interface, click Status at the top, then nd your IP Address and write it down.

D-Link DCS-960L Specifications

General

Type	IP security camera
Day/night mode	Yes
Placement supported	Indoor
Connectivity technology	Wireless
Form factor	Cube
Mounting type	Desk
Product color	Black
Minimum illumination	0 lx
Field of view (FOV) angle	180 °
Total megapixels	1 MP
Maximum resolution	1280 x 720 pixels
Supported video modes	720p
Video formats supported	H.264, M-JPEG
Supported graphics resolutions	320 x 240, 640 x 360, 640 x 480 (VGA), 720 x 480, 800 x 600 (SVGA), 1280 x 720 (HD 720)
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
LED type	IR
Night vision distance	4.8 m
Detection distance	0.5 m
Security algorithms	WEP, WPA, WPA2, WPS
DC output voltage	5
Power over Ethernet (PoE)	-
Power consumption (typical)	4.8 W
Frequency band	2.4/5 GHz
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 4 (802.11n)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-Fi data rate (max)	433 Mbit/s
Audio formats supported	G.711
Sensor type	CMOS
Optical sensor size	1/2.7 \
Interface	WLAN
Number of cameras	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Width	95.8 mm
Height	137.5 mm
Weight	165 g
