10/100 Dual-Speed Switch User’s Guide
26
Connecting The Switch
The LED indicators on the DES-1008D switch for the respective
connected ports are as follows:
1.
The 100M indicator (LED) lights for a 100 Mbps link and
stays dark for 10 Mbps.
2.
The Link/Act LED indicator illuminates upon hookup.
3.
The FDX LED indicator lights for full-duplex, remains dark
for a half-duplex link, and blinks when collisions take place.
