D-Link DGS-1008P Quick Installation Guide

DGS-1008P
2
ENGLISH
PACKAGE
CONTENTS
CONTENTS
If any of these items are missing from your packaging, contact your reseller.
Warning:
Using a power adapter with a different voltage rating will damage and void the
warranty of this product.
• DGS-1008P 8-Port Gigabit Unmanaged Desktop Switch
• Power Adapter (54 V, 1.67 A)
• Power Cable
• Mounting Kit
• 4 Rubber Feet
• Quick Install Guide
INTRODUCTION
The D-Link DGS-1008P Gigabit Unmanaged Desktop Switch is capable of feeding power to
Power over Ethernet (PoE) devices such as network cameras. The DGS-1008P has 8 ports
operating at 10/100/1000 Mbps with 4 PoE+ ports (Ports 1 to 4) with a total PoE budget of 68W,
making it ideal for home and small ofce use.

D-Link DGS-1008P Specifications

General

MAC address table	8000 entries
Store-and-forward	Yes
Packet buffer memory	0.256 MB
Packet forwarding rate (1 Gbps)	14880 pps
Packet forwarding rate (10 Mbps)	1488000 pps
Packet forwarding rate (100 Mbps)	148800 pps
10G support	No
Networking standards	IEEE 802.3, IEEE 802.3ac, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Switch type	Unmanaged
Power connector	DC-in jack
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Product color	Black
Rack mounting	-
LED indicators	Activity, Link, PoE, Power, Speed, Status
Total Power over Ethernet (PoE) budget	68 W
Power over Ethernet (PoE) ports quantity	4
Power over Ethernet (PoE) power per port	30 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Input current	1.5 A
Noise level	0 dB

Weight and Dimensions

Depth	120 mm
Width	190 mm
Height	38 mm
