DGS-1008P
4
ENGLISH
CONNECTING THE DGS-1008P TO YOUR NETWORK
A. POWER
Plug the AC power cord into a free outlet or surge protector, then plug the other end of the DC
power jack into the power port of the DGS-1008P. The Power LED will illuminate conrming that
the device has powered up successfully.
B. PoE PORTS (PORTS 1 - 4)
PoE Ports 1 to 4 support 802.3at for up to 30W per port for individual usage.
C. GIGABIT PORTS (PORTS 1 - 8)
These ports offer network speeds of either 10 Mbps, 100 Mbps or 1000 Mbps and can operate
in half or full-duplex transfer modes. These ports also support automatic MDI/MDIX crossover,
eliminating the need for crossover cables or uplink ports. Each port can be connected directly to
a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables.
4 PoE Ports
8 10/100/1000 Mbps
Ports
