DIR-815 AC1200 Wave 2 MU-MIMO Wi-Fi

Router with 3G/LTE Support and USB Port

User Manual

Configuring via Web-based Interface

UDPXY

On the Advanced / UDPXY page, you can allow the router to use the built-in UDPXY

application. The UDPXY application transforms UDP traffic into HTTP traffic. This application

allows devices which cannot receive UDP streams to access stream video.

Figure 149. The Advanced / UDPXY page.

To enable the application, move the Enable switch to the right.

Upon that the following fields are displayed on the page:

Parameter Description

Port

The port of the router which the UDPXY application uses.

Maximum client number

Maximum number of devices from the router's LAN which will be

served by the application.

Buffer size for incoming

data

Size of intermediate buffer for received data.

By default, the minimum acceptable value is specified.

Buffer size for data

transferred to client

Size of intermediate buffer for transmitted data.

By default, the minimum acceptable value is specified.

WAN interface

From the drop-down list, select a WAN connection which will be

used for operation with streaming video.

After specifying the needed parameters, click the APPLY button.

Page 190 of 240
