User Manual of DIR-825M
-16-
Rear Panel
Figure 2-1-3-1 Rear Panel of the DIR-825M
Interface Description
On/off
button
Power On/Off button
Power
Connector
Connect to the power adapter provided in the package
WPS Press it will enable WPS functiont
Reset
Press the Reset button gently for 3 seconds and then release it. The system
restores to the factory default settings
