D-Link DIR-825M

User Manual of DIR-825M
-62-
Figure 5-3-2-3-1 IP Filtering
Object Description
Enable IP Filtering Enable or disable IP Filtering function.
Enable IPv4 Enable or disable IPv4 Filtering feature.
Enable IPv6 Enable or disable IPv6 Filtering feature.
Local IPv4 Address Set LAN side source IPv4 address
Local IPv6 Address
Set LAN side source IPv6 address
Protocol Select “TCP”, “UDP” or” Both”
Comment
Comment for the rule.
5.3.2.4. Port Filtering
