User Manual of DIR-825M
-7-
1.3 Product Specifications
Model
DIR-825M
1200Mbps 802.11ac Dual Band Wireless Gigabit Router
Hardware Specifications
Interface
WAN Port: 1 x 10/100/1000 Mbps auto MDI/MDI-X RJ45 port
LAN Port: 4 x 10/100/1000 Mbps auto MDI/MDI-X RJ45 port (LAN1~4)
USB Port: 1 x USB 2.0, Type A, 5V 500mA
Antenna Gain:
2x5dBi 2.4g external antenna
2x5dBi 5g external antenna
Button
1 x reset button
1 x WPS button
LED Indicators
POWR x 1
WAN x 1
LAN x 4
WLAN x 2
WPS x 1
USB x 1
Material Plastic
Dimensions (W x D x H)
192x 118x 31 mm (W x D x H)
Weight 322g
Power Requirement 12V DC, 1A
Power Consumption 9W
Wireless Interface Specifications
Standard
IEEE 802.11ac 5GHz
IEEE 802.11a/n 5GHz
IEEE 802.11b/g/n 2.4GHz
Frequency Band
Simultaneous 2.4GHz and 5GHz
Modulation Type
802.11ac: OFDM (BPSK / QPSK / 16QAM / 64QAM / 256QAM)
802.11a/g/n: OFDM (BPSK / QPSK / 16QAM / 64QAM)
802.11b: DSSS (DBPSK / DQPSK / CCK)
