D-Link DMS-1250 Series User Manual

DMS-1250 Series Multi-G Ethernet Smart Managed Switch Hardware Installation Guide
27
Appendix A - Technical Specifications
General
Physical and Environmental
Performance
LED Indicators
Port Functions
General
Feature Description
Data Transfer Rates Half-duplex Full-duplex
Ethernet 10 Mbps 20 Mbps
Fast Ethernet 100 Mbps 200 Mbps
Multi-G Ethernet - 5~10Gbps
10 Multi-G Ethernet - 20 Gbps
Network Cables UTP/STP Category 3, 4, 5 for 10BASE-T
UTP/STP Category.5, 5e for 100BASE-TX
UTP/STP Category 5e for 1000/2.5G/5GBASE-T
UTP/STP Category 6a for 10GBASE-T
Physical and Environmental
Feature Description
Internal AC Power Supply
DMS-1250-10S:100~240VAC, 50~60Hz, 0.35A
DMS-1250-10SP: 100~240VAC, 50~60Hz, 3.48A
DMS-1250-12TP: 100~240VAC, 50~60Hz, 3.51A
DMS-1250-10SPL: 54V/2.78A external power adapter
Security Lock Provides a Kensington-compatible security lock, on the rear panel of the
Switch, to be able to connect to a secure immovable device. Insert the
lock into the notch and turn the key to secure the lock. The lock-and-
cable apparatus should be purchased separately
Fans
The IC Sensor detects the temperature on the switch automatically and
adjusts the speed.
DMS-1250-10S: Fanless
DMS-1250-10SP: 2 fans
DMS-1250-12TP: 2 fans
DMS-1250-10SPL: Fanless
Power Consumption Maximum Power Consumption:
DMS-1250-10S: 13.522 Watts
DMS-1250-10SP: 21.221 Watts (w/o PoE), 287.58 Watts (PoE on)
DMS-1250-12TP: 28.33 Watts (w/o PoE), 289.74 Watts (PoE on)
DMS-1250-10SPL: 10.274 Watts (w/o PoE), 147 W (PoE on)
Standby Power Consumption:
DMS-1250-10S: 5.443 Watts
DMS-1250-10SP: 10.936 Watts
DMS-1250-12TP: 14.020 Watts
DMS-1250-10SPL: 10.274W Watts
Temperature Operating:
0~50 °C for DMS-1250-10-10S/DMS-1250-10SP/DMS-1250-12TP
0~40 °C for DMS-1250-10SPL
