D-Link DMS-1250 Series User Manual

DMS-1250 Series Multi-G Ethernet Smart Managed Switch Hardware Installation Guide
28
Feature Description
Storage: -20 °C to 70 °C (-4 °F to 158 °F)
Humidity Operating: 0 % to 95 % RH (non-condensing)
Storage: 0 % to 95 % RH (non-condensing)
Heat Dissipation DMS-1250-10S: 46.33 BTU/hr
DMS-1250-10SP: 981.223 BTU/hr
DMS-1250-12TP: 988.63 BTU/hr
Dimensions
DMS-1250-12T: 440x210x44mm
DMS-1250-10S/10SP: 330x200x44mm
Weight DMS-1250-10S: 1.877 kg (4.14 lbs)
DMS-1250-10SP: 2.377 kg (5.24 lbs)
DMS-1250-12TP: 3.24 kg (7.14 lbs)
DMS-1250-10SPL:1.34 kgs (2.95 lbs)
EMC Certifications CE Class A, FCC Class A, ISED Class A, VCCI Class A, RCM Class A,
BSMI Class A
Safety Certifications IEC60950-1, IEC62368-1, UL/CSA62368-1, BSMI Class A
Performance
Feature Description
Transmission Method Store-and-forward
Packet Buffer 12 Mbits per device
Jumbo Frame Size 12KB
Switching Capacity
DMS-1250-10S: 80Gbps
DMS-1250-1SP: 80Gbps
DMS-1250-12TP: 120Gbps
DMS-1250-10SPL: 80Gbps
Maximum Packet Forwarding Rate
DMS-1250-10S: 59.53Mpps
DMS-1250-10SP:59.53Mpps
DMS-1250-12TP:89.29Mbps
DMS-1250-10SPL: 59.53Mpps
Priority Queues 8 Priority Queues per port.
MAC Address Table
DMS-1250-10S: 16K
DMS-1250-10SP: 16K
DMS-1250-12TP: 16K
DMS-1250-10SPL: 16K
Supports 256 Static MAC addresses
