D-Link DP-301P+ Quick Installation Guide

3
Setting up your DP-301P+ for network
printing in Windows XP
The factory default IP address of the DP-301P+ is 192.168.0.10. In order to
connect to the printer through the DP-301P+, the DP-301P+ must have the
same IP network settings as your network. IP address can be assigned manually
or automatically by DHCP, BOOTP or RARP. To access the print server’s web
conguration, manually assign an IP address on one of the PC’s on your network
to the same subnet as the print server.
For additional Windows operating system setup or information
on the web-management interface, refer to the manual located
on the CD-ROM. For Mac OS printing, please refer to the
manual located on the CD-ROM.
Go to Start > right click on
My Network Places >
select Properties > Double-click on
the Network Connection associated
with your Network Adapter.
Input a static IP address in the
same range as the print server.
Click OK
Click Internet Protocol (TCP/IP)
Click Properties
Select Use the following IP address
IP address: 192.168.0.52
Subnet mask: 255.255.255.0

D-Link DP-301P+ Specifications

General

Networking standards	-
Ethernet LAN data rates	10, 100 Mbit/s
Network connection type	Ethernet LAN
Copper ethernet cabling technology	100BASE-TX, 10BASE-T
Supported network protocols	TCP/IP, NetBEUI, AppleTalk, LPR, SMB, IPP
DC-in jack	Yes
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Flash memory	2 MB
Internal memory	8 MB
Internal	No
Product color	Gray
LED indicators	Power
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 95, Windows 98, Windows 98SE, Windows ME, Windows NT, Windows XP Home, Windows XP Home x64, Windows XP Professional
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Safety	UL, LVD
Certification	FCC B, CE B, C-Tick
Cabling technology	10/100Base-T(X)
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	52.6 mm
Width	85.6 mm
Height	25.9 mm
