D-Link DP-301P+ User Manual

6
LAN Port - Network Cable Connector
The print server’s rear panel features a LAN port for connection to Ethernet/Fast
Ethernet cabling (which should be CAT5 twisted-pair cable). The port supports the
NWay protocol, allowing the print server to automatically detect or negotiate the
transmission speed of the network. Use this port to connect to your network router.
Power - DC Power Connector
The DC power input connector is located on the print server’s rear panel .
LED Indicators
The back panel of the print server features three LED indicators:
ACT - Lights up to indicate activity on the network.
LPT - Lights up to indicate printing activity.
1 - Lights up to indicate that the DP-301P+ is powered ON.
Rear Panel
Power
LEDs
LAN Port

D-Link DP-301P+ Specifications

General

Networking standards	-
Ethernet LAN data rates	10, 100 Mbit/s
Network connection type	Ethernet LAN
Copper ethernet cabling technology	100BASE-TX, 10BASE-T
Supported network protocols	TCP/IP, NetBEUI, AppleTalk, LPR, SMB, IPP
DC-in jack	Yes
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Flash memory	2 MB
Internal memory	8 MB
Internal	No
Product color	Gray
LED indicators	Power
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 95, Windows 98, Windows 98SE, Windows ME, Windows NT, Windows XP Home, Windows XP Home x64, Windows XP Professional
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Safety	UL, LVD
Certification	FCC B, CE B, C-Tick
Cabling technology	10/100Base-T(X)
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	52.6 mm
Width	85.6 mm
Height	25.9 mm
