Setting up your DP-301U for network
printing in Windows XP
The factory default IP address of the DP-301U is 192.168.0.10. In order to print to
the printer(s) through the DP-301U, the DP-301U must have the same IP network
settings as your network. IP address can be assigned manually or automatically by
DHCP, BOOTP or RARP. To access the print server’s web conguration, manually
assign an IP address on one of the PC’s on your network to the same subnet as
the print server.
For additional Windows operating system setup or information on
the web-management interface, refer to the manual located on the
CD-ROM.
Go to Start > right click on My Network
Places > select Properties > Double-click
on the Network Connection associated
with your Network Adapter.
Input a static IP address in the same
range as the print server.
Click Internet Protocol (TCP/IP)
Click Properties
Select Use the following
IP address
IP address: 192.168.0.52
Subnet mask: 255.255.255.0
Click OK
To Next Page
