D-Link DSL-224 Quick Installation Guide

DSL-224 Quick Installation Guide
SPECIFICATIONS
*
Hardware
Processor
· RTL8685S
RAM
· 32MB, SDRAM
Flash
· 8MB, SPI
Interfaces
· RJ-11 DSL port
· 4 10/100BASE-TX LAN ports
LEDs
· POWER
· DSL
· INTERNET
· WLAN
· 4 LAN LEDs
· WPS
Buttons
· ON/OFF button to power on/power off
· RESET button to restore factory default settings
· WPS button to set up wireless connection
· WLAN button to enable/disable wireless network
Antenna
· Two internal omnidirectional antennas (2dBi gain)
MIMO
· 2 x 2
Power connector
· Power input connector (DC)
DSL Parameters
VDSL/ADSL Standards
· VDSL2: ITU G.993.2, support of 8a, 8b, 8c, 8d, 12a,
12b, 17a, 30a profiles
· ADSL: Multi-mode, ANSI T1.413 Issue 2, ITU-T G.992.1
(G.dmt) Annex A, ITU-T G.992.2 (G.lite) Annex A, ITU-T
G.994.1 (G.hs)
· ADSL2: ITU-T G.992.3 (G.dmt.bis) Annex A/L/M, ITU-T
G.992.4 (G.lite.bis) Annex A
· ADSL2+: ITU-T G.992.5 Annex A/L/M
* The device features are subject to change without notice. For the latest versions of the
firmware and relevant documentation, visit www.dlink.ru.
35

D-Link DSL-224 Specifications

General

Flash memory	8 MB
Certification	CE, RoHS
Internal memory	32 MB
Built-in processor	Yes
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
SIM card slot	No
WAN connection type	RJ-11
VPN support	IPSec/PPTP/L2TP/PPPoE
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Mac operating systems supported	Mac OS X 10.4 Tiger
Windows operating systems supported	Windows 7, Windows 8, Windows Vista, Windows XP
Security algorithms	WDS, WEP, WMM, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	2 dBi
Power source type	AC
Product type	Tabletop router
Product color	White
LED indicators	DSL, LAN, Power, WAN, WLAN, WPS
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	100 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s

Weight and Dimensions

Depth	26 mm
Width	172 mm
Height	114 mm
