DSL-2640U Quick Installation Guide
6. On the VoIP page, select the Is an IP phone connected to the
device checkbox.
7. Select a free LAN port for connecting your IP phone.
8. For the Ethernet (LAN) mode: If the VoIP service is provided via a
VLAN channel, select the Use VLAN ID checkbox and fill in the VLAN
ID field.
9. For the ADSL mode: Specify the VPI and VCI values in the relevant
fields.
10. Click the NEXT button.
27
