D-Link DSR-1000N User Manual

D-Link DSR-Series User Manual 200
Section 10 - Status and Statistics
Status and Statistics
Path: Status > Dashboard
The router provides a dashboard that displays about the resources the system is using. The dashboard page is
organized into the following sections:
Field Description
Trac Overview Displays a chart of trac overview by service for each interface.
WAN Ports Displays a chart of trac overview by bandwidth and packet information for WAN trac.
Bandwidth Usage
Displays bandwidth usage by network segment such as WAN or LAN. The data is broken into by applications
service such as HTTP, HTTPS, DNS, SNMP, and others.
VPNs Displays a chart of VPN trac by bandwidth and number of tunnels.
Trac Information Displays a grid of trac statistics for each interface.
Dashboard

D-Link DSR-1000N Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Frequency range	2.4GHz
xDSL connection	No
Dimensions (WxDxH)	180 x 280 x 44 mm
USB ports quantity	2
Firewall security	RIPv1, RIP v2, OSPF
Security algorithms	WPA, WPA-PSK, WPA2-PSK
MAC address filtering	-
Ethernet LAN (RJ-45) ports	4
Safety	cUL, LVD (EN60950-1)
Certification	FCC B, CE B, VCCI, C-Tick, IC
Mean time between failures (MTBF)	260000 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Product color	Black

Weight and Dimensions

Weight	- g
