DW R -116
2
ENGLISH
1. ACCESSING THE WEB UI
To access the Web UI of the DWR-116, connect your computer to the DWR-116 using the ethernet
cable provided. Then connect the power cable to the DWR-116.
Then simply open a browser window and enter the IP address in the browser address eld:
IP ADDRESS: http://192.168.0.1
USERNAME: admin
PASSWORD: <blank>
WEB UI

Other manuals for D-Link DWR-116

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DWR-116 and is the answer not in the manual?

D-Link DWR-116 Specifications

Data Rates and Standards IconData Rates and Standards
data rates in 802.11n mode300, 150, 135, 120, 90, 60, 45, 30, 15 Mbps
data rates in 802.11g mode6/9/11/12/18/24/36/48/54Mbps
data rates in 802.11b mode1/2/5.5/11Mbps
Frequency and Security IconFrequency and Security
frequency2.4 - 2.4835 GHz
wireless security64/128-bit WEP, WPA & WPA2
Ports and Antenna IconPorts and Antenna
ports4 x LAN (RJ-45), 1x WAN, 1 x USB
Power and Dimensions IconPower and Dimensions
power adapterExternal 5 V DC 2 A
dimensions148.5 x 113.5 x 25 mm, 5.85 x 4.47 x .98 inches
Operating Environment IconOperating Environment
operating temperature0 to 40 °C, 32 to 104 °F
operating humidity10% to 95% non-condensing
