D-Link DWR-978 Quick Installation Guide

DWR-978
4
ENGLISH
1. HOW DO I CONFIGURE MY DWR-978 ROUTER OR CHECK MY WIRELESS NETWORK NAME (SSID)
AND WIRELESS ENCRYPTION KEY?
• Connect your PC to the router using an Ethernet cable.
• Open a web browser and enter the router's IP address: http://192.168.0.1
• Log into the router by leaving the password area blank.
• Once logged in, you will be prompted to change the password from the default.
• Use the wizard located under Internet settings to congure the router, or make changes
manually.
Note: If you have changed the password and cannot remember it, you will need to reset the
router to factory defaults.
2. HOW DO I RESET MY DWR-978 ROUTER TO FACTORY DEFAULT SETTINGS?
• If you cannot remember your router’s administrator password, you may use a paperclip to press
and hold the reset button on the router for about 10 seconds.
Note: Resetting the router to factory default will erase the current conguration. To recongure
your router, log in as outlined in question 1, then run the Setup Wizard.
3. HOW DO I ADD A NEW WIRELESS DEVICE OR PC IF I HAVE FORGOTTEN MY WIRELESS
NETWORK NAME (SSID) OR WIRELESS ENCRYPTION KEY?
• Every device that needs to connect to the router wirelessly will need use the correct Wireless
Network Name (SSID) and encryption key.
• Use the web-based user interface (as described in question 1 above) to check or choose your
wireless settings.
• Make sure you write down these settings so that you can enter them into each wirelessly-
connected PC. You will nd a dedicated area on the back of this document to note this important
information down for future use.
4. WHY AM I UNABLE TO ESTABLISH AN INTERNET CONNECTION?
• If connecting using a mobile connection, make sure that you are within range of the mobile
service provider, and that the service has been correctly congured.
• If connecting using WAN via an ADSL/Cable service, make sure the modem has been enabled/
connected and is operational, and that the service is correctly congured.
TROUBLESHOOTING
TECHNICAL SUPPORT
eu.dlink.com/support

D-Link DWR-978 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
3G/4G USB modem compatibility	-
4G standard	LTE-FDD
3G standards	WCDMA
SIM card type	NanoSIM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2600 Mbit/s
WLAN data transfer rate (first band)	800 Mbit/s
WLAN data transfer rate (second band)	1733 Mbit/s
Product type	Tabletop router
Product color	White
LED indicators	LTE, Power, WAN, WLAN
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11k, IEEE 802.11r, IEEE 802.11v
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Security algorithms	WPA, WPA2, WPA3
Antennas quantity	8
Output current	1 A
Output voltage	12 V
Power source type	AC
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Mobile operating systems supported	Android, iOS
Number of products included	1 pc(s)
Sustainability certificates	CE, RoHS

Weight and Dimensions

Depth	245 mm
Width	234.5 mm
Height	55.25 mm
Weight	920 g
