29D-Link EBR-2310 User Manual
Section 3 - Conguration
This will allow you to open a single port. If you would like to open a range of ports, refer to page 30.
Enter a name for the rule or select an application from the drop-down
menu. Select an application and click << to populate the elds.
Enter the IP address of the computer on your local network that you
want to allow the incoming service to. If your computer is receiving an
IP address automatically from the router (DHCP), you computer will be
listed in the “Computer Name” drop-down menu. Select your computer
and click <<.
Enter the port that you want to open next to Private Port and Public Port.
The private and public ports are usually the same. The public port is the
port seen from the Internet side, and the private port is the port being
used by the application on the computer within your local network.
Select TCP, UDP, or Both from the drop-down menu.
The schedule of time when the Virtual Server Rule will be enabled. The
schedule may be set to Always, which will allow the particular service
to always be enabled. You can create your own times in the Tools >
Schedules section.
Name:
IP Address:
Private Port/
Public Port:
Trac Type:
Schedule:
