D-Link EXO AX DIR-X1560 User Manual

5D-Link DIR-X1560 User Manual
Section 1 - Product Overview
Back Panel
1
1
Gigabit LAN Ports
(1- 4)
Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game
consoles.
2 Gigabit WAN Port Using an Ethernet cable, connect your broadband modem to this port.
3 Reset Button
Insert a paperclip in the hole, wait for 10 seconds, and release to reset the router to default
settings.
4 WPS Button
Press to start the WPS process and automatically create an encrypted connection to a WPS
client.
5 Power Connector Connector for the supplied power adapter.
6 Power Button Press the power button to power the device on or o.
2 3 4 5 6

D-Link EXO AX DIR-X1560 Specifications

General

Wi-Fi Technology	Wi-Fi 6 (802.11ax)
Dual Band	Yes
Maximum Data Rate	1500 Mbps
Antenna Type	External
MU-MIMO	Yes
OFDMA	Yes
Beamforming	Yes
USB Port	No
LAN Ports	4 x Gigabit
WAN Ports	1 x Gigabit
Wireless Speed	1200 Mbps on 5GHz, 300 Mbps on 2.4GHz
Security	WPA3
