D-Link EXO AX DIR-X4860-US User Manual

5D-Link DIR-X4860 User Manual
Section 1 - Product Overview
Back Panel
1 USB 2.0 Port Connect a USB storage device to share les over the network.
2 USB 3.0 Port Connect a USB storage device to share les over the network.
3
Gigabit LAN Ports
(1- 4)
Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game
consoles.
4 Gigabit WAN Port Using an Ethernet cable, connect your broadband modem to this port.
5 WPS Button
Press to start the WPS process and automatically create an encrypted connection to a WPS
client.
6 Reset Button
Insert a paperclip in the hole, wait for 10 seconds, and release to reset the router to default
settings.
7 Power Connector Connector for the supplied power adapter.
8 Power Button Press the power button to power the device on or o.
3 7 84 6
5
1 2

D-Link EXO AX DIR-X4860-US Specifications

General

Brand	D-Link
Model	EXO AX DIR-X4860-US
Category	Wireless Router
Language	English
