1 Hardware Installation D-Link Web Smart Switch User Manual
Then, use the screws provided with the equipment rack to mount the switch in the rack.
Figure 3 – Mount the Switch in the rack or chassis
Step 3 – Plugging in the AC Power Cord
Users may now connect the AC power cord into the rear of the switch and to an electrical outlet (preferably
one that is grounded and surge protected).
Figure 4 –Plugging the switch into an outlet
Power Failure
As a precaution, the switch should be unplugged in case of power failure. When power is resumed, plug the
switch back in.
