DAB GENIX VT Instruction For Installation And Maintenance

ENGLISH
AUS
5
Operation by means of a power drill
1. Disconnect the power supply
2. If the product cannot be operated by electrical power, the toilet and sys-
tem can be emptied by means of a power drill.
Pressure switch pipe clogged
1. Disconnect the power supply
2. Unscrew the screw of the motor cover and remove the cover
3. If the water level is above the motor ange, empty the tank by means of
the appropriate tap and the hose (supplied).
4. Unscrew the screws of the board holder.
5. Remove the pressure switch pipe.
6. Clean the rubber hose and check the opening on the tank.
Foreign body in tank
1. Disconnect the power supply
2. Unscrew the screw of the motor cover and remove the cover
3. If the water level is above the motor ange, empty the tank by means of
the appropriate tap and the hose (supplied).
4. Unscrew the side screw of the motor ring
5. Lift the motor ange to reduce the compression of the O-ring. Insert a
screwdriver into the notch underneath the supply cable and press it down.
6. Extract the complete motor unit by means of the handles (lift the unit
vertically before tilting it).
7. Check and clean the tank and impeller/grinder.
Carbon lter
1. Remove the lter cover
2. Replace the lter
The carbon lter should be replaced once a year to ensure su󰀩cient
lter function.
Instead of using the activated carbon lter, the system can also vent
through a vent pipe with diameter 20.
7. TECHNICAL DATA
Model Hz
Volt
(V) P1 (W)
Amp
(A) Cos ᵠ
Hmax
pump
(m)
Flow
max
(m3/h)
Genix VT 50 220-240 530 2.5
0.95
0.91
8.0 7.8
• Supply voltage: see electrical data plate
• Maximum operating pressure: 90 kPa / 0.9 bar / 13 psi
• Grade of motor protection: IP44
• Protection rating: F
• Noise level: <70dB(A) to EN 12050-3
• Delayed line fuses (version 220-240v): indicative values (Ampere)
• Duty: S3 -50% 1min. (30 sec on; 30 sec o󰀨).
• Ambient temperature: da +5°C a +35°C
• Start and stop levels:
Start: 72 mm above bottom
Stop: 52 mm above bottom
The system pressure should not exceed 6 m head to guarantee a
su󰀩cient drain of the connected sanitary appliances (see rapid
guide).
• Storage temperature: -10°C +40°C
• Marking:
8. MANAGEMENT
8.1 Storage
All the pumps must be stored in a dry covered place, with possible con-
stant air humidity, free from vibrations and dust.
They are supplied in their original pack in which they must remain until the
time of installation.
