PART NAMES
1 One touch door open button Push to open door.
2 Oven door with see-through window
3 Safety door latches
The oven will not operate unless the door is securely closed.
4 Door hinges
5 Door seals and sealing surfaces
6 Turntable motor shaft
7 Removable turntable support
Carefully place the turntable support in the center of the oven floor.
8 Removable turntable
Place the turntable on the turntable support securely. The turntable will
rotate clockwise or counterclockwise. Only remove for cleaning.
9 Ventilation openings (Rear)
10 Oven light
It will light when oven is operating or door is open.
11 Waveguide cover: DO NOT REMOVE.
12 Control panel
13 Touch Screen
