Dacor ERV3015 - Page 12

10
Installation Specifications
Model A B C
ERV3015
12 1/8”
(30.7 cm)
5 5/8”
(14.4 cm)
1 3/4”
(4.4 cm)
ERV3615
9 3/4”
(24.8 cm)
8”
(20.3 cm)
4 1/4”
(10.8 cm)
ERV
ADAPTER
8 7/8" (22.5 cm)
from back of ERV
cutout to center
line of CABP3
exhaust in any
orientation
Bottom exhaust
configuration shown
DUCT
C
L
CABP3
Cooktop
29 1/4”
(74.3 cm)
Duct connection
center line
C
Downdraft vent
center line
Countertop
3
1
/4 x 10
duct connection
Duct connection
center line
B
Downdraft vent
center line
Countertop
3
1
/4 x 10
duct
connection
15 3/8”
(39.1 cm)
Duct connection
center line
A
Downdraft vent
center line
Countertop
3
1
/4 x 10
duct
connection
26 1/4”
(66.7 cm)
Exhaust Locations and Side Dimensions
for CABP3 Cabinet blower
Exhaust Locations and Dimensions
for CABP3 Cabinet Blower Installations
(ERV3015, ERV3615 only)
Front Exhaust Dimensions
CABP3 Blower - Bottom Exhaust
Front Exhaust Dimensions
CABP3 Blower - Right Exhaust
Front Exhaust Dimensions
CABP3 Blower - Left Exhaust
