8
Backer Panel
Overlay Panel
Spacer Panel
1
/
4
" (6.4 mm)
3
/
4
" (1.9 cm)
1" (2.5 cm)
1
/
2
" (1.3 cm)
1"
1
1
/
4
"
1
1
/
2
"
1"
(2.5 cm)
1
(3.2 cm)
1
/
4
"
1
(3.8 cm)
1
/
2
"
1
/
2
"
Refrigerator
Side Trim
Door
Hinge
(2.5 cm)
(3.2 cm)
(3.8 cm)
(1.3 cm)
Cabinetry
3
/
4
"
(1.9 cm)
110˚ Door
Stop Position
Installation Requirements
The custom door panels and adjacent cabinetry for models series IF42 and IF48 must be designed so that there is sufficient clearance
for the doors to swing open. If the refrigerator is to be installed close to the wall, see Door Swing 90° on facing page.
When the doors are closed the refrigerator will extend beyond the face of the adjacent cabinetry to some degree.
NOTE: For IF Series models, rout the
hinge side of the custom door panels
to a radius that is equal to at least half
the thickness of the panel if a 130°
door swing is desired. See Adjust
Doors.
Door Panels and Cabinetry Clearance - IF42/IF48 Series Models
Door Swing 110°
Actual Size
Refrigerator to
Cabinetry Clearance
To Next Page
