Installation requirements
Installation requirements
Cutout requirements
Cutout dimensions (W x H x D) : 42” x 84” x 24” (1067 x 2134 x 610 mm)
• Install the refrigerator so that it can be pulled away from the wall if service becomes
necessary.
• The ooring under the refrigerator must be level with the kitchen ooring. (The
refrigerator cannot be on a raised or lowered oor.)
• The face of the surrounding cabinetry must be plumb.
• Water line can enter the opening through the oor or rear wall. The water line should
be used for supplied connecting between the cold water line and water connection
location. The line should be long enough to extend to the front of the refrigerator.
Installation of an easily accessible shutoff valve in the water line is required.
• It is recommended that you use a mat to prevent the oor from damage.
WARNING
• Make sure a dedicated, grounded,
3-prong outlet is installed to supply
electrical power to the refrigerator.
• Use a 3-prong power cord plugged
directly into the grounded outlet. Do
not alter into a 2-prong power cord or
use a power strip.
• Make sure the house’s main water
supply is accessible where the
refrigerator will be placed. Water is
needed for the refrigerator’s ice maker
and drinking water dispenser.
• See the suggested water line locations
in the image below.
