Installation instructions
Secure refrigerator to furniture
Whenever possible, perform this step for anti-tip security.
Raise Grille Panel
to Stop Position.
Drive Screws Through
Case Trim Into Adjacent
Cabinets.
The refrigerator must be secured to
prevent tipping.
• Raise the grille panel to access case
trim.
• Drive a screw through the trim and into
the adjacent FURNITURE using holes
provided.
• Follow the same procedure on the
opposite side.
Connect water supply
Check to make sure that Master Power Switch is in the “O” (OFF) position.
Compression Nut
Compression Nut
Compression tting
Sleeve
Ferrule
Connect a hose from refrigerator and
water line, installed to water pipe like
above gure.
• Turn on the water to check for leaks.
NOTE
Make sure excess tubing length does not
interfere with kickplate installation.
