RX6020 / RX6620 / RX7320 / RX7620

When you do install the front loader, install the bolts for the mounting bracket at the indicated points.

•

WARNING

FIXATION POINTS FOR FRONT END LOADER

M55O627A

[Left hand side of front axle frame]

[Left hand side of clutch housing]

[The beneath of rear transmission]

[Right hand side of front axle frame]

[Right hand side of clutch housing]
