17
To lock the steering, turn the handlebars
all the way to the left or right, turn the key
to LOCK while pushing in.
Remove the key.
To unlock the steering, turn the key to
OFF while pushing in.
< FRONT SEAT >
To remove the front seat, insert the
ignition key into the seat lock.
Turn the ignition key counterclockwise,
and then pull the seat back and up.
To install the front seat, insert the tab into
the recess under the frame and push down
on the rear of the seat.
< REAR SEAT >
To remove the rear seat, remove both
front seat and center cover, remove the
seat mounting bolt, and then pull the seat
front and up.
To install the seat, insert the tab into the
recess under the frame and tighten the
mount bolt scurely.
STEERING LOCK SEAT
WARNING
Do not turn the key to LOCK while
riding the vehicle driving.
EQUIPMENT USAGE
KEY
TAB
FRONT SEAT
FRONT SEAT
CENTER
COVER
REAR SEAT
MOUNTING BOLT
PUSH IN
TURN TO
LOCK
