Clutch adjustment may be reguired if the
motorcycle stalls when shifting into gear
or tends to creep; or if the clutch slips,
causing acceleration to lag behind engine
speed.
Minor adjustments can be made with the
clutch cable adjuster at the lever.
CLUTCH LEVER FREE PLAY:10~20mm
<CLUTCH LEVER ADJUSTMENT>
1. Loosen the lock nut and turn the
adjuster. Tighten the lock nut and check
the adjustment.
2. If the adjuster is threaded out near its
limit or if the correct free play cannot
be obtained, loosen the lock nut and
turn in the cable adjuster completely.
Tighten the lock nut.
3. Loosen the lock nut at the lower end of
the cable. Turn the adjusting nut to
obtain the specified free play. Tighten
the lock nut and check the adjustment.
4. Start the engine, pull in the clutch lever
and shift into gear. Make sure the
engine does not stall and the motorcycle
does not creep. Gradually release the
clutch lever and open the throttle.
The motorcycle should begin to move
smoothly and accelerate gradually.
