HOW TO INSTALL THE DRAIN HOSE (PUMP MODEL)
Installation Of The Drain Hose
Never forget to install drain hose before operating this washing
machine.
When machine. When the packing box is opened, there are
a drain hose, a clamp, and a hose fixture.
NOTES:
1. Keep the drain hose fixed tightly in the hose fixture
2. Be sure that the height of the “U” shaped outlet is more
than 1m above the floor. If not so, the water in the washer
could be drained during operation
3. Be sure that the height of the drain hose must be less
than 1.5m above the floor.
If not so, the water in the washer could not drain.
4. Connect drain hose th tub or standpipe.
The hose guide, included in the accessory kit, is to guide
the drain hose over the tub or standpipe.
It MUST be fitted to the drain hose.
The drain hose should not extend more than 20mm from
the end of the guide (this is to prevent syphoning).
It the necessary the drain hose can be trummed to lenght.
1
Connect the drain hose to the drain
outlet at the back side of the washing
machine, and fasten it tightly with the
clamp supplied.
2
Insert the hose fixture into hook
hole on the left side or right side
of the body.
3
Fix the drain hose by inserting
it into the hose fixture.
4
Hang the guide drain hose on
the edge of a sink.
HOW TO CONNECT THE INLET HOSE
IN INSTALLING THE INLET HOSE
Be careful not to mistake in supplying hot and cold water.
In using only one water tap, connect the inlet hose to the
cold water inlet.
1
Connect the inlet
hose to the water tap
by screwing the
connector D tightly.
To Next Page
