25
4. Pull out fan and remove screws.
5. Remove motor cover by turning it slowly.
6. Remove wire fastening tape and pull out the Motor.
F and R Fan Motor are distinguished by their wire colors,
so be careful not to change the motors.
- Blue Wire for R Fan Motor
- Red Wire for F Fan Motor
See to it that wire out direction is correct.
7-1. Exchange of Defrosting Sensor
1. Remove defrosting sensor on the top right of evaporator.
DISASSEMBLY AND ASSEMBLY
