1. To remove cabinet
1) Remove three screws on cabinet back.
2) Pull the cabinet backward.
2. To remove door assembly
1) Remove a screw which secure the stopper hinge
top.
2) Remove the door assembly from top plate of cavity.
3) Reverse the above for reassembly.
NOTE : After replacing the door assembly, perform a check of correct alignment with the hinge and cavity front plate.
