Daewoo 14A5 - Electrical Parts List

LOC. PART-CODE PART-NAME PART-DESCRIPTION REMARK
ZZ100 48BRM01A01 TRANSMITTER REMOCON RM-01A01
00030 47P7500001 BATTERY AAM 1.5V
ZZ131 58G0000084 COIL DEGAUSSING DC-1450
ZZ132 48519A4610 CRT GROUND AS 1401H-1015-1P
V901 4859606240 CRT A34EAC01X-AT1625/31
A001 4859801493 PCB MAIN 330X246 D1B
SP01 4858306810 SPEAKER 3W 16 OHM F2035C03-3
C102 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C103 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C104 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C105 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C106 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C107 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C108 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C109 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C110 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C111 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C115 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C116 CCZF1E223Z C CERA 25V F 0.022MF Z (AXIAL)
C117 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
C118 CZCH1H100J C CERA 50V CH 10PF J (AXIAL)
C120 CEXD1H109F C ELECTRO 50V RND 1MF (5X11) TP
C301 CMXB2A104J C MYLAR 100V EU 0.1MF J (TP)
C302 CCZB1H181K C CERA 50V B 180PF K (AXIAL)
C303 CCZB1H181K C CERA 50V B 180PF K (AXIAL)
C304 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C306 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C308 CEXF1E471V C ELECTRO 25V RSS 470MF (10X16) TP
C309 CEXF2A470V C ELECTRO 100V RSS 47MF (10X16) TP
C311 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C312 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C401 CBZR1C472M C CERA 16V Y5R 4700PF M (AXIAL)
C402 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C403 CBZR1C222M C CERA 16V Y5R 2200PF M (AXIAL)
C404 CCZB1H181K C CERA 50V B 180PF K (AXIAL)
C406 CCXB1H222K C CERA 50V B 2200PF K (TAPPING)
C409 CCXB3D471K C CERA 2KV B 470PF K (TAPPING)
C410 CMYH3C622J C MYLAR 1.6KV BUP 6200PF J
C411 CMYE2D514J C MYLAR 200V PU 0.51MF J
43
Components marked with this symbol must only be replaced by a component having
identical physical characteristics.
Electrical Parts List
MODEL : C14M7E
