NO NAME SYMBOL SPECIFICATION PART CODE Q TY
1 BUZZER BZ1 BM-20K 3515600100 1
2 C ARRAY CA1 7P(6) 102 M 50V CN6XB-102M 1
3 CAPACITOR ELEC EC1 50V RS 1 F CEXE1H109V 1
4 CPAPCITOR ELEC EC2 25V RSS 1000 F CEXF1E102V 1
5 CONNECTOR WAFER CN1 YW396-02AV 3519150520 1
6 CONNECTOR WAFER CN3 YW396-05AV 3519150510 1
7 CONNECTOR WAFER CN2 FCZ 254-11 441M367160 1
8 DIODE RECTIFY
D1~6, 9~12,15
1N4148 DZN4148--- 11
9 DIODE RECTIFY D13, 14 1N4004A DZN4004A-- 2
10 DIODE ZENER ZD1 UZ-5.1BSB DZUZ5R1BSB 1
11 DIODE ZENER ZD2 UZ-3.9BSB DZUZ3R9BSB 1
12 LED DISPLAY DP1 DDG-631H DDDG631H01 1
13 PCB MAIN M158 81.5X139.9 3514315410 1
14 R ARRAY RA1 7P(6) 1/8 100K J RA-87X104J 1
15 RESISTOR R1~R7 1/6W 220 5% RD-AZ221J- 7
16 RESISTOR
R8, 10, 12, 14, 22
1/6W 1K 5% RD-AZ102J- 5
17 RESISTOR R11, 20, 21 1/6W 100K 5% RD-AZ104J- 3
18 RESISTOR R13 1/6W 200 5% RD-AZ201J- 1
19 RESISTOR R15~16 1/6W 10K 5% RD-AZ103J- 3
20 RESISTOR R17 1/6W 510 5% RD-AZ511J- 1
21 RESISTOR R18 1/6W 1M 5% RD-AZ105J- 1
22 RESISTOR R19 1/4W 51 5% RD-4Z510J- 1
23 REGULATOR VL1 MC7905C 1MC7905C-- 1
24 TRANSISTOR Q1~5, 9~11 KRA-106M TZRA106M-- 8
25 TRANSISTOR Q6 KTA-1266Y TZTA1266Y- 1
26 TRANS POWER LVT1 DMR-631P 5EPU035302 1
27 WIRE COPPER
J1~3,5~8,10~12,17~21
1/0.52 TIN COATING 85801052GY 15
28 WIRE COPPER SJ3, 5 1/0.52 TIN COATING 85801052GY 2
29 IC MICOM IC1 TMP47C440BN-NG14 13GS1A1AGH0 1
30 RESONATOR CERA CR1 KBR-4.0MSTF 5PKBR40MKS 1
31 SW RELAY RY1 G5G-1A DC 12V 5SC0101121 2
32 SW RELAY RY2 CS11-12SH 1C 1P 5SC0101128 1
33 CAPACITOR CERA C6 102 50V Z AXIAL CCZB1H102K 1
34 CAPACITOR CERA
C1, C3~C5, C7
104 50V Z AXIAL CCZF1H104Z 5
