Electrical Parts List
225M 225MU 325M 325MU
PART-CODE PART-DESC
MODEL
NO ASS'Y LOCATION PART-NAME
421 PCB MAIN AS JW910 WIRE JUMPER W581GY7595 AWG22 1/0.65 SN 7.5 AUTO o o o o
422 PCB MAIN AS JW911 WIRE JUMPER W581GY7595 AWG22 1/0.65 SN 7.5 AUTO o
423 PCB MAIN AS JW940~941 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
424 PCB MAIN AS JW943 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
425 PCB MAIN AS JW952 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
426 PCB MAIN AS JW957 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o
427 PCB MAIN AS JW958 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
428 PCB MAIN AS JW959 WIRE JUMPER W581GY6095 AWG22 1/0.65 SN 6 AUTO o
429 PCB MAIN AS JW960 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o
430 PCB MAIN AS JW961 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
431 PCB MAIN AS JW962 WIRE JUMPER W581GY6095 AWG22 1/0.65 SN 6 AUTO o o o o
432 PCB MAIN AS JW963 WIRE JUMPER W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO o o
433 PCB MAIN AS JW965 WIRE JUMPER W581GY1505 AWG22 1/0.65 GY 15 AUTO o o o o
434 PCB MAIN AS JW966 WIRE JUMPER W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO o o o o
435 PCB MAIN AS L001 COIL PEAKING 5CPZ100K02 10UH K (AXIAL 3.5MM) o o o o
436 PCB MAIN AS L101 AM RF UNIT 5LR0000834 RBW07VB-K5024 o o o o
437 PCB MAIN AS L251 COIL PEAKING 5CPZ100K02 10UH K (AXIAL 3.5MM) o o o o
438 PCB MAIN AS L601 COIL OSC 5L00000500 0500 10X10 BK o o o o
439 PCB MAIN AS L801~802 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o
440 PCB MAIN AS Q001 TR TZTC3194Y- KTC3194Y o o o o
441 PCB MAIN AS Q003 TR TZRA107M-- KRA107M (KSR2006) o o o o
442 PCB MAIN AS Q501 TR TZTA1266Y- KTA1266Y- (AUTO)(1015Y) o o o o
443 PCB MAIN AS Q502 TR TZTA1273Y- KTA1273Y(966Y) o o o o
444 PCB MAIN AS Q503 TR TZTC3198Y- KTC3198Y-(1815Y) (AUTO) o o o
445 PCB MAIN AS Q503 TR TZRC107M-- KRC107M(AUTO) o
446 PCB MAIN AS Q601~602 FET TKTK117Y-- KTK117(Y) o o o o
447 PCB MAIN AS Q603~604 TR TZTA1266Y- KTA1266Y- (AUTO)(1015Y) o o o o
448 PCB MAIN AS Q605 TR TZTC3198Y- KTC3198Y-(1815Y) (AUTO) o o o o
449 PCB MAIN AS Q607 TR TZTC3198Y- KTC3198Y-(1815Y) (AUTO) o o o o
450 PCB MAIN AS Q612 TR TZRC111M-- KRC111M o o o o
451 PCB MAIN AS Q613 TR TZTC3198Y- KTC3198Y-(1815Y) (AUTO) o o o o
452 PCB MAIN AS Q614 TR TZRC107M-- KRC107M(AUTO) o o o o
453 PCB MAIN AS Q615~620 TR TZTC3198Y- KTC3198Y-(1815Y) (AUTO) o o o o
454 PCB MAIN AS Q621 TR TZTA1273Y- KTA1273Y(966Y) o o o o
455 PCB MAIN AS Q801~802 TR TZTD1302Y- KTD1302Y AUTO o o o
456 PCB MAIN AS Q801~802 TR TZTC3198Y- KTC3198Y-(1815Y) (AUTO) o
457 PCB MAIN AS Q803 TR TZRA111M-- KRA111M o o o o
458 PCB MAIN AS Q804 TR TZTC3198Y- KTC3198Y-(1815Y) (AUTO) o o o o
459 PCB MAIN AS R002 WIRE JUMPER W581GY6095 AWG22 1/0.65 SN 6 AUTO o o o o
460 PCB MAIN AS R003 R CARBON FILM RD-AZ470J- 1/6 47 OHM J o o o o
461 PCB MAIN AS R004 R CARBON FILM RD-AZ100J- 1/6 10 OHM J o o o o
462 PCB MAIN AS R005 R CARBON FILM RD-AZ332J- 1/6 3.3K OHM J o o o o
463 PCB MAIN AS R006 R CARBON FILM RD-AZ681J- 1/6 680 OHM J o o o o
464 PCB MAIN AS R007 R CARBON FILM RD-AZ331J- 1/6 330 OHM J o o o o
465 PCB MAIN AS R008 R CARBON FILM RD-AZ101J- 1/6 100 OHM J o o o o
466 PCB MAIN AS R012 R CARBON FILM RD-AZ331J- 1/6 330 OHM J o o o o
467 PCB MAIN AS R101 R CARBON FILM RD-AZ472J- 1/6 4.7K OHM J o o o o
468 PCB MAIN AS R103~105 R CARBON FILM RD-AZ472J- 1/6 4.7K OHM J o o o o
469 PCB MAIN AS R106 R CARBON FILM RD-AZ332J- 1/6 3.3K OHM J o o o o
470 PCB MAIN AS R107 R CARBON FILM RD-AZ223J- 1/6 22K OHM J o o o o
471 PCB MAIN AS R109 R CARBON FILM RD-AZ104J- 1/6 100K OHM J o o o o
472 PCB MAIN AS R201 R CARBON FILM RD-AZ822J- 1/6 8.2K OHM J o o o o
473 PCB MAIN AS R202 R CARBON FILM RD-AZ273J- 1/6 27K OHM J o o o
474 PCB MAIN AS R202 R CARBON FILM RD-AZ223J- 1/6 22K OHM J o
475 PCB MAIN AS R203 R CARBON FILM RD-AZ822J- 1/6 8.2K OHM J o o o o
476 PCB MAIN AS R204 R CARBON FILM RD-AZ562J- 1/6 5.6K OHM J o o o o
477 PCB MAIN AS R205~206 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
478 PCB MAIN AS R207 R CARBON FILM RD-AZ121J- 1/6 120 OHM J o o o o
479 PCB MAIN AS R208 R CARBON FILM RD-AZ332J- 1/6 3.3K OHM J o o o o
480 PCB MAIN AS R209 R CARBON FILM RD-AZ472J- 1/6 4.7K OHM J o o o o
481 PCB MAIN AS R210 R CARBON FILM RD-AZ682J- 1/6 6.8K OHM J o o o o
482 PCB MAIN AS R211 R CARBON FILM RD-AZ100J- 1/6 10 OHM J o o o o
483 PCB MAIN AS R212~213 R CARBON FILM RD-AZ182J- 1/6 1.8K OHM J o o o o
484 PCB MAIN AS R216 R CARBON FILM RD-AZ473J- 1/6 47K OHM J o o o o
485 PCB MAIN AS R217~218 R CARBON FILM RD-AZ822J- 1/6 8.2K OHM J o o o o
486 PCB MAIN AS R219~220 R CARBON FILM RD-AZ223J- 1/6 22K OHM J o o o o
487 PCB MAIN AS R221 R CARBON FILM RD-AZ563J- 1/6 56K OHM J o o o
488 PCB MAIN AS R221 R CARBON FILM RD-AZ333J- 1/6 33K OHM J o
489 PCB MAIN AS R251 R CARBON FILM RD-AZ102J- 1/6 1K OHM J o o o o
490 PCB MAIN AS R252 R CARBON FILM RD-AZ470J- 1/6 47 OHM J o o o o
